Steel Frame Electric Wheelchair Long Range Lead Acid Battery Electromagnetic Brake Medical Certified
This heavy duty steel frame electric wheelchair is specially engineered for institutional and wholesale market demands, perfectly matching procurement needs of rehabilitation hospitals long term care nursing homes and global mobility equipment distributors. We select thickened steel tube frame as main support structure to enhance overall structural toughness, solving the easy deformation issue of thin aluminum wheelchairs under frequent daily use in care facilities.
The core safety configuration adopts standard industrial electromagnetic brake system. The wheel locks automatically once the joystick control lever is released. It can hold the wheelchair steadily on sloped ground even when power cuts off unexpectedly, greatly lowering fall accident risks for elderly and disabled users and reducing safety liability concerns for institutional operators.
Dual 250W rear drive motors provide stable traction power with maximum climbing gradient of 8 degree. The front 10 inch solid tires avoid air leakage troubles during long term institutional use, while 16 inch inflatable rear tires deliver shock absorption and smooth riding experience on rough roads. The multifunctional joystick controller features simple speed adjustment horn and power buttons, requiring minimal training time for nursing staff to operate proficiently.
The wheelchair supports a maximum safe load of 110KG and achieves 25 plus minus 5 kilometers driving distance on one full charge with 24V12AH lead acid battery packs. Foldable frame design helps save storage space inside care wards and cuts container transportation volume for bulk wholesale orders, improving profit space for distributor partners.
Complete Technical Parameter Table
表格
| Parameter Item | Detailed Specification |
|---|---|
| Overall Dimension Length Width Height | 9165110cm |
| Outer Carton Packing Size | 833975cm |
| Max Forward Travel Speed | 6KM Per Hour |
| Maximum Climbing Gradient | 8 Degree |
| Single Charge Full Driving Range | 25±5KM |
| Maximum Safe Loading Weight | 110KG |
| Front Wheel Tire Spec | 10 Inch Solid Rubber Tire |
| Rear Drive Wheel Tire Spec | 16 Inch Inflatable Air Tire |
| Drive Layout | Rear Wheel Drive |
| Safety Brake Mode | Intelligent Electromagnetic Brake |
| Standard Battery Configuration | 24V 12AH Lead Acid Battery Set |
| Matching Charger Parameter | 24V 2A Output Charger |
| Standard Full Charging Duration | 3 To 6 Hours |
| Dual Drive Motor Power | Two Units Of 250W Motors |
| Motor Controller Spec | 24V 50A Brushless Controller |
Why Choose This Steel Frame Electric Wheelchair
- High Durability Steel Frame For Institutional Heavy Usage Thick reinforced steel main frame resists bending and wear under daily repeated use in nursing homes and rehabilitation centers. Less frame damage rate reduces after sales repair frequency for distributors and cuts long term equipment replacement cost for medical institutions.
- Balanced Tire Combination Lowers Daily Maintenance Workload Solid front tires eliminate regular air refilling and puncture repair work, suitable for high frequency ward transfer use. Large inflatable rear wheels absorb road bumps to improve user comfort, forming differentiated selling points compared with full solid tire competitors in the market.
- Stable Long Distance Battery Performance For All Day Shift Use 24V12AH large capacity lead acid batteries support up to 25km continuous travel. It fully meets all day outdoor rehabilitation activity demands of care facilities, avoiding frequent mid day charging interruptions for nursing work schedules.
- Complete Wholesale Support System For Distributors We offer tiered volume based unit price discounts for batch orders. Neutral export carton packaging and OEM brand printing services are available for large purchase quantities. Full product test documents can be supplied to assist tender submission for hospital and senior care center bidding projects.
- Simple Operable Control Panel Reduces Staff Training Cost Intuitive joystick controller with speed plus minus horn and power buttons has low learning threshold. New nursing employees can master operation within minutes, cutting labor training expenditure for institutional clients.
FAQ
- Is the steel frame wheelchair suitable for elderly ward mass configuration procurement? Absolutely. The sturdy steel structure supports up to 110KG load capacity and withstands long term daily shift use. We can provide batch order quotation and complete product qualification documents for hospital tender audit requirements.
- What advantages does lead acid battery bring for nursing home bulk orders? Lead acid batteries feature lower unit purchase cost compared with lithium batteries, matching the limited equipment budget of most public senior care facilities. Stable supply channels guarantee synchronized delivery with wheelchair bulk shipments.
- Does the electromagnetic brake meet international medical mobility safety standards? The fail safe electromagnetic braking system complies with mainstream medical mobility equipment safety norms. The brake locks wheels instantly without power supply to prevent sliding on slopes, a mandatory safety feature for rehabilitation facility equipment procurement standards.
- What is the minimum order quantity for distributor cooperation? Small trial batch orders are acceptable for new mobility equipment dealers. Larger order volumes correspond to more favorable unit prices. Contact our sales team to obtain official detailed price list and delivery schedule.
- Can customized packaging and brand logo printing be arranged for wholesale orders? OEM and ODM customization services are supported for orders above specified quantity. Custom printed brand marks on cartons and wheelchair frames can be arranged without hidden extra processing charges.
- Does the product support ocean freight export to overseas markets? Standard export neutral carton packaging is included for all bulk orders. We can provide complete battery transport certification materials to support smooth customs clearance for cross border wholesale shipments.
